IKO Hyload Gastite DPC
Product documents
Category: Structural Waterproofing
Sector of Application: DPC
Product Type: Bituminous
Product Information
Description
SBS modified bitumen DPC system with a 50 micron aluminium core. This core gives greater material resistance to the passage of radon, carbon dioxide and methane. When used within a suitably designed ground gas system, it serves to resist gas migration into the cavity of the masonry wall construction.
Features and Benefits
- Gas Resistant – a 50 micron aluminium core gives an improved material resistance to gas permeation
- Excellent Mortar Bond – when installed in between fresh beds of mortar, the product displays excellent mortar adhesion and bond properties.
- Developed Components – as part of the IKO Hyload brand, the product has a full range of system components.
Colour: Black
Product Finish: Sand
Installation Method: Laid into Mortar
Project Type: Commercial Large, Commercial Medium, Commercial Small, Domestic Large, Domestic Medium
Documents
Product Variations
IKO Hyload Gastite DPC
| SKU | Unit weight kg | Width mm | Thickness mm | Length mm | Product colour | Product finish |
| 37310000 | 100 | 3 | 8000 | Black | Sand | |
| 37399900 | 27.7 | 1000 | 3 | 8000 | Black | Sand |
| 37311200 | 112.5 | 3 | 8000 | Black | Sand | |
| 37315000 | 150 | 3 | 8000 | Black | Sand | |
| 37320000 | 200 | 3 | 8000 | Black | Sand | |
| 37322500 | 225 | 3 | 8000 | Black | Sand | |
| 37327500 | 275 | 3 | 8000 | Black | Sand | |
| 37330000 | 300 | 3 | 8000 | Black | Sand | |
| 37332500 | 325 | 3 | 8000 | Black | Sand | |
| 37333700 | 337.5 | 3 | 8000 | Black | Sand | |
| 37335000 | 350 | 3 | 8000 | Black | Sand | |
| 37337500 | 375 | 3 | 8000 | Black | Sand | |
| 37340000 | 400 | 3 | 8000 | Black | Sand | |
| 37342500 | 425 | 3 | 8000 | Black | Sand | |
| 37345000 | 450 | 3 | 8000 | Black | Sand | |
| 37347500 | 475 | 3 | 8000 | Black | Sand | |
| 37350000 | 500 | 3 | 8000 | Black | Sand | |
| 37352500 | 525 | 3 | 8000 | Black | Sand | |
| 37355000 | 550 | 3 | 8000 | Black | Sand | |
| 37357500 | 575 | 3 | 8000 | Black | Sand | |
| 37360000 | 600 | 3 | 8000 | Black | Sand | |
| 37365000 | 650 | 3 | 8000 | Black | Sand | |
| 37367500 | 675 | 3 | 8000 | Black | Sand | |
| 37370000 | 700 | 3 | 8000 | Black | Sand | |
| 37372500 | 725 | 3 | 8000 | Black | Sand | |
| 37375000 | 750 | 3 | 8000 | Black | Sand | |
| 37380000 | 800 | 3 | 8000 | Black | Sand | |
| 37390000 | 900 | 3 | 8000 | Black | Sand | |
| 37395000 | 950 | 3 | 8000 | Black | Sand |
Features & benefits
Features and benefits
- Gas Resistant – a 50 micron aluminium core gives an improved material resistance to gas permeation
- Excellent Mortar Bond – when installed in between fresh beds of mortar, the product displays excellent mortar adhesion and bond properties.
- Developed Components – as part of the IKO Hyload brand, the product has a full range of system components.
Description
SBS modified bitumen DPC system with a 50 micron aluminium core. This core gives greater material resistance to the passage of radon, carbon dioxide and methane. When used within a suitably designed ground gas system, it serves to resist gas migration into the cavity of the masonry wall construction.
The products primary area of use is within hazardous ground gas systems; however it can also be used within masonry walls to prevent passage of moisture from the ground and at all levels as cavity tray to prevent the downward movement of water.
As the product is sand surfaced, is achieves an excellent bond with mortar and can be used to provide protection under situations of minimal loading such as parapet walls, under throated coping stones and under brick-on edge detailing for both solid masonry and cavity wall construction.
Accreditations
Accreditations
GAS RESISTANT
Other
Product attributes
MEMBRANE CARRIER: Polyester
MEMBRANE MODIFIER: SBS
THERMAL PERFORMANCE: Non-Insulated
