IKO Armourplan PVC – Single Ply Roofing System
IKO’s Armourplan PVC single ply roofing system offers flexible and durable waterproofing solution across a wide range of roofing applications, including specialist installations such as simulated metal roofs.
Single ply roofing systems have become a popular choice for specifiers in the last 30 years. These systems offer many advantages but the biggest benefit they offer is that they are a light-weight solution. Specifiers can minimise the roof zone depth and enjoy more flexibility in design.
Single ply roofing systems also offer a fast-track and safe installation as no hot works or frames are involved in the process.
IKO Armourplan is suitable for warm or cold roofs whether the roof is flat, inverted, or sloped and can be mechanically fastened, adhered or ballasted providing maximum system flexibility. It is available in either 1.2mm or 1.5mm thicknesses
Produced in a range of different membranes, each designed for specific applications, the range comes in two standard colours; mid grey (RAL 7046) and slate grey (RAL 7015).
Also available in light grey (RAL7047) and bespoke colours are available to meet project requirements, please contact your local representative for details.
System Benefits
- Exceptional mechanical properties and product performance
- Available in either 1.2mm or 1.5mm thicknesses
- High UV resistance and a long service life
- Efficient and safe installation
- Secure seam welding quality
- Aesthetically pleasing finish
- Complete range of accessories available
- Bespoke colours available on request
NBS Source Data
IKO Armourplan SM - Mechanically Fixed Single Ply Cold Roof System - 10/15/20 Year Guarantee
NBS Source Data
Mechanically Fixed Single Ply Warm Roof System - IKO Armourplan P - 20/25 Year Guarantee - Warm roof system
NBS Source Data
Mechanically Fixed Single Ply Warm Roof System - IKO Armourplan SM - 10/15/20 Year Guarantee
NBS Source Data
Single Ply Roof System - IKO Armourplan PSG - 10/15/20/25 Year Guarantee
Typical build up option
IKO Armourplan
Adhered Roofing System
- Armourplan® PSG*, SG*, SM** or P**
- IKOpro Low Foaming PU Adhesive, Armourplan® PVC Contact Adhesive or Sprayfast FMA / PCA
- IKO Supertherm Insulation
- Bonded Bituminous Vapour Control Layer
- Suitable Deck
IKO Armourplan
Mechanically Fastened
Roofing System
-
Armourplan® SM or Armourplan® P Mechanically Fixed
-
IKO enertherm ALU or MG Insulation
-
Spectravap Polyethylene VCL (or Bonded Bituminous VCL)
-
Suitable Deck
IKO Armourplan
Inverted & Ballasted Roofing System
- Ballast and/or Concrete Paving Loading Coat
- Paving Support Pads
- Spectratex Fleece
- Extruded Polystyrene (loose laid)
- Armourplan® SG or PSG (adhered or loose laid) or Armourplan® P/SM (loose laid or fixed)
IKO Armourplan
Warm Ballasted Roofing System
-
Ballast and/or Concrete Paving Loading Coat
-
Spectratex Fleece
-
Paving Support Pads
-
Armourplan® P, SM (loose laid)
-
IKO Supertherm Insulation
-
Spectravap VCL (loose laid)
-
Suitable Deck
Case Studies
You can speak to a local specialist about your project
IKO offer a comprehensive service and full support
– from design and specification through to project sign off.
Contact your local IKO specialist for further details
.
.
